RG TransferLine™
RTC-30 Battery Rail Transfer Car
Battery-electric rail transfer car, 30,000 kg rated capacity, all-wheel drive — no trailing cable, no festoon.
Product datasheet available on request.
Gallery
Additional views
Overview
About this equipment
The RTC-30 runs on embedded or surface-laid rail between bays, carrying its own 76.8V LFP battery pack so there is no trailing cable to snag, no conductor rail to install, and no festoon system to maintain. All four wheels are independently driven by geared motors, giving consistent traction under full load in both directions of travel.
No trailing cable. No conductor rail. No festoon system. The RTC-30 carries its own power, which removes the track-side electrical infrastructure a conventional rail car needs and the maintenance load that comes with it — no cable reel to service, no collector shoes to replace, no festoon trolleys to realign.
Deck size is confirmed to your load — a typical 4000 × 2000 mm deck at 750 mm loading height suits most bay-transfer applications, with the frame, wheelbase and rail specification (52 kg/m) engineered around your actual stock or billet dimensions.
Designed, fabricated and supported from our ISO 9001:2015 certified facility in Indore. As an Indian-made machine, lead times, spares and service response are shorter than an imported equivalent.
Key features
- Rated capacity: 30,000 kg
- Drive: 4 × 3 kW geared motors — all wheels driven
- Battery: 76.8 V LFP (lithium iron phosphate)
- Wheels: Ø450 mm double-flanged, forged, 320–350 BHN
- Control: Radio remote + pendant
- Structure: IS 2062 E250 BR
Materials of construction
- IS 2062 E250 BR structural steel
Standards referenced
- IS 2062 E250 BR — structural steel
- IS 807 — design of structures for handling equipment
- IS 816 — welding
- ISO 13850 Category 1 — emergency stop
- IEC 62619 — industrial lithium battery safety
Technical data
Specifications
Values below are as published by RG Steel Crafts. Application-specific figures are confirmed at quotation stage.
- Rated capacity
- 30,000 kg
- Deck size
- To suit load (typical 4000 × 2000 mm)
- Loading height
- 750 mm
- Travel speed
- 40 m/min
- Drive
- 4 × 3 kW geared motors — all wheels driven
- Battery
- 76.8 V LFP (lithium iron phosphate)
- Wheels
- Ø450 mm double-flanged, forged, 320–350 BHN
- Rail
- 52 kg/m
- Control
- Radio remote + pendant
- Structure
- IS 2062 E250 BR
Available on request
The following details are confirmed per application and are not published as fixed values:
- Tare (unladen) weight
- Battery capacity (Ah) and charge time
- Enclosure / IP rating
- Maximum incline or grade capability
- Overall length and width (deck-dependent)
